Chisel-tine action
The tines penetrate and loosen the soil rather than turning a furrow with a mouldboard.
Tillage & Soil PreparationAgricultural implement
Chisel cultivator
A tine-based chisel cultivator for loosening soil through forward tractor movement.
- Product family
- Tillage & Soil Preparation
- Models
- 3 configurations
Product & applications
About the chisel cultivator
A tine-based chisel cultivator for loosening soil through forward tractor movement.
Features & benefits
Three tine-count options
The 1LHS series lists five-, seven- and nine-tine versions with different working widths.
Depth and traction matching
The specified working depth must be considered together with soil conditions and tractor traction.
Typical applications
- Deep cultivationLoosen suitable farmland using the chisel tines and selected working depth.
- Clod breakupBreak clods during soil preparation. The tines loosen the soil through tractor traction rather than through a PTO-powered rotor.
Models, dimensions and working requirements
|
Item |
No. of tine(pc) |
Working depth(mm) |
Working width(mm) |
Weight (kg) |
Matched power(hp) |
| JY-1LHS -5 |
5 |
200-350 |
1200 |
200 |
55-75 |
| JY-1LHS -7 |
7 |
200-350 |
1500 |
260 |
80-100 |
| JY-1LHS -9 |
9 |
200-350 |
1800 |
350 |
110-150 |
Installation requirements
Confirm the implement fits your tractor
Before ordering, send the machine identification and the connection, power and working information relevant to this product.
Tractor and traction
Compare the model-specific tractor-power range, implement weight and the traction required in the actual soil.
Rear mounting
Match the actual rear linkage and lifting capacity to the chosen frame and working width.
Working geometry
Check working width, tine spacing, cultivation depth and turning space at the field ends.
Soil and field conditions
Describe soil texture, moisture, residue and field access. This family works through tractor movement without a PTO-driven rotor.
Product questions
Chisel cultivator questions
How does it differ from a mouldboard plough?
A chisel cultivator loosens soil with tines. A mouldboard plough cuts and turns furrows through a different body geometry.
How should I choose the working width and tine layout?
Check working width, tine spacing, cultivation depth and turning space at the field ends.
What should I check before installation?
Compare the model-specific tractor-power range, implement weight and the traction required in the actual soil. Match the actual rear linkage and lifting capacity to the chosen frame and working width.
