Single-shank penetration
The concentrated working point breaks up hard soil and compacted ground before bucket excavation.
Groundwork & PilingJY-RER series · Excavator attachment
Excavator ripper
A single-shank excavator attachment for loosening hard soil, compacted ground and suitable soft rock before excavation.
- Carrier range
- 1.5–45 t
- Working mechanism
- Single-shank ground loosening
Product & applications
About the excavator ripper
A single-shank excavator attachment for loosening hard soil, compacted ground and suitable soft rock before excavation.
Features & benefits
Reinforced structural design
The shank and mounting structure transmit excavator digging force into the ground.
Adjustable tooth arrangement
An adjustable tooth arrangement accommodates different soil conditions.
Simple maintenance
The ripper uses a ground-engaging mechanical structure without a powered cutting or vibrating mechanism.
Typical applications
- Hard soil and clayLoosen hardpan, compacted earth and clay before excavation and loading.
- Soft-rock excavationBreak up suitable soft rock using the shank and tooth before a bucket removes the loosened material.
- Land reclamation and site preparationPrepare ground on construction, agricultural and mining sites. Confirm formation hardness; a ripper is not a universal substitute for a hydraulic breaker.
Ripper models and mounting dimensions
| Model | Unit | JY-RER-mini | JY-RER-04 | JY-RER-06 | JY-RER-08 | JY-RER-10 | JY-RER-17 |
|---|---|---|---|---|---|---|---|
| Excavator | T | 1.5-4 | 5-9 | 10-18 | 19-24 | 25-32 | 36-45 |
| lbs | 3307-8818 | 11023-19842 | 22046-39683 | 41888-52911 | 55116-70548 | 79366-99208 | |
| Weight | kg | 50 | 80 | 200 | 450 | 550 | 1000 |
| Pin To Pin Distance | mm | 85-200 | 220-310 | 390 | 465 | 515 | 580 |
| Total Width | mm | 260 | 320 | 430 | 530 | 610 | 680 |
| Total Height | mm | 310 | 420 | 530 | 670 | 700 | 800 |
| Total Length | mm | 700 | 800 | 1000 | 1400 | 1620 | 1720 |
| Pin Diameter | mm | 25-40 | 45-55 | 60-70 | 70-80 | 90 | 100-120 |
| Arm Width | mm | 90-150 | 180-230 | 220-315 | 300-350 | 350-410 | 370-480 |
Installation requirements
Confirm the attachment fits your excavator
Before ordering, send the machine identification and the connection, power and working information relevant to this product.
- D1 / D2
- Both pin diameters
- C
- Pin centre distance
- W
- Clear mounting width
Excavator and attachment weight
Use the selected model carrier range and check the actual machine lifting and digging limits.
Pin-on mounting
Confirm both pin diameters, pin centres and the clear arm width against the selected model.
Ground conditions
Describe soil hardness, rock conditions and buried obstructions. A passive ripper is not a hydraulic hammer.
Working clearance
Check the tooth path and shank clearance throughout the excavator linkage movement.
Product questions
Excavator ripper questions
Is this ripper hydraulically powered?
The referenced single-shank ripper is a passive attachment. The excavator linkage provides the working force.
Can it replace a bucket?
It loosens ground; use a bucket to excavate and load the loosened material.
Can I choose using excavator weight alone?
No. Also confirm the actual mounting connection, attachment weight and excavator lifting capacity. Powered tools need the specified hydraulic supply.
Which information is needed for a quotation?
Send the excavator model, mounting dimensions, work requirements, quantity and delivery destination.
